Process connection
Thread standard, male/female form, sealing method and mating component.
APP-01 · Application
Instrumentation & Measurement
Connection parts for pressure gauges, sensors, transmitters and related instrument assemblies.
Application qualification
Inputs required beyond the part drawing
These questions establish the actual system boundary and inspection basis.
Operating conditions
Medium, normal and maximum pressure, temperature and test requirement.
Instrument interface
Bore, concentricity, dead volume, cleanliness and installation envelope.
Inspection
Thread gauges, critical dimensions, material records and leak-test responsibility.
Responsibility boundaries
Pressure ratings are not assigned from a similar-looking adapter.
Instrument accuracy and system certification remain outside the machined-part scope unless contracted.
Related products
Products for Instrumentation & Measurement
Related product types provide a practical starting point. Final suitability is defined by the drawing and application inputs above.
BFC-PI-01Pressure & Instrumentation
Pressure Gauge Adapter
- Male or female connection
- NPT, BSP, G, metric or drawing
- Hex and bore geometry
BFC-PI-02Pressure & Instrumentation
Pressure Gauge Socket
- Instrument thread
- Bore and sealing face
- Body length and material
BFC-PI-03Pressure & Instrumentation
Sensor / Transmitter Adapter
- Sensor-side thread
- Process-side connection
- Bore and concentricity
BFC-PI-04Pressure & Instrumentation
Instrument Manifold Block
- Port count and port map
- Thread or tube interface
- Block envelope and passages
BFC-CF-01Compression Fitting Bodies
Straight Compression Fitting Body
- Tube outside diameter
- Connection thread
- Cone and body geometry
BFC-CF-02Compression Fitting Bodies
Bulkhead Union Body
- Tube outside diameter
- Panel thickness
- Body thread and hex
Discuss a Instrumentation & Measurement project
Send the drawing, mating interfaces, operating conditions and target quantity for a structured review.
