Straight Compression Fitting Body
Straight Compression Fitting Body made to drawing, with connection geometry, material, inspection and supply scope confirmed before quotation.
View drawing checklistCustom Brass Compression Fitting Bodies
Custom brass compression fitting and connector bodies made to drawing, with tube interfaces, process threads, sealing geometry and supply boundaries confirmed before quotation.
Define the fitting body and the assembly scope separately
This family covers machined brass fitting bodies made to drawing. A body quotation does not automatically include a nut, ferrule, seal or complete tested connector.
- 1
Send the tube interface and mating-component drawing, including the seat geometry and assembly requirements.
- 2
Choose a straight body or bulkhead body; for bulkhead parts include panel thickness, mounting length and locknut requirements.
- 3
List the requested material, quantity and inspection requirements, and identify any additional components as separate quotation items.
Choose the closest part type, then define your specification
These are manufacturing starting points rather than fixed catalog ratings. Your approved drawing controls the final part.
Custom Brass Compression Bulkhead Union Body
Custom Brass Compression Bulkhead Union Body made to drawing, with connection geometry, material, inspection and supply scope confirmed before quotation.
View drawing checklistMale / Female Connector Body
Male / Female Connector Body made to drawing, with connection geometry, material, inspection and supply scope confirmed before quotation.
View drawing checklistCompression Nut & Ferrule Set
Compression Nut & Ferrule Set made to drawing, with connection geometry, material, inspection and supply scope confirmed before quotation.
View drawing checklistDefine the interfaces before quotation
Made-to-drawing fitting bodies reviewed against the required tube interface, process thread and mating geometry. Nut or ferrule supply is confirmed separately in the quotation.
- 01Tube outside diameter
- 02Compression interface
- 03Process thread
- 04Assembly supply boundary
Connect the drawing to real operating conditions
Instrumentation & Measurement
Connections for gauges, sensors and transmitters reviewed around pressure, sealing, thread and instrument integration.
Valve & Flow ControlMachined valve bodies and components reviewed with the pressure boundary, seats, media and test responsibility clearly defined.
Pneumatic & Industrial EquipmentConnection bodies for pneumatic and industrial equipment reviewed around air passages, hose or tube interfaces, burr control and leakage.
No rating or certification is assigned by appearance.
See the quality routeMaterial, pressure, temperature, media compatibility, testing and compliance remain project-specific until reviewed.
Request a Quote for a Custom Brass Part
Send the available information. Missing technical decisions are identified before quotation.
